Description
The LDO Galileo 2 G2E / G2SA Extruder Kit is a direct replacement for the CW2 extruder in Voron printers with Stealthburner toolheads or many community toolhead(XOL, A4T) with G2SA. It features a large 16mm drive gear paired with an idler bearing to reduce extrusion issues and a planetary gearbox that eliminates gear-meshing noise. It is compatible with all current toolhead boards for SB and suitable for most community tool heads such as XOL, A4T or Dragon Burner.
Note: Current stock kits are latest REV C batch. (If you're looking for G2Z or G2Z XL those are separate listings)
Custom 9:1 Planetary Gearbox Design
Core Specifications
- 9:1 MJF & Aluminium planetary gearbox
- Custom 9T stepper with 5mm spur gear
- 20% increased surface area vs. 10T (4mm) designs
- 3-planet configuration
- Optimised tooth meshing (9T sun gear divisible by 3 planets)
Key Engineering Principles
- Enhanced wear protection
- Improved power transfer
- Precise gear tooth engagement
- Optimised mechanical efficiency
Performance Attributes
- Increased durability
- Reduced mechanical stress
- Precision-engineered load distribution
Printed Parts?
Not included with this product but you can request print request them as an optional or you can print yourself here: https://github.com/JaredC01/Galileo2
https://store.dremc.com.au/products/print-job
[Estimated cost for standard G2E Extruder Parts $62 (include GST)] 2-3 business day lead time. [Contact us for colour option and material availability (Default Material: DREMC PC ABS)].
What is included:
Galileo 2 Extruder Kit by LDO includes the following list:
- LDO-36STH20-1004AHG(9T) Stepper Motor, 1 piece
- Ring Gear Housing MFJ, 1 piece
- Planetary Gears, 3 pieces
- Aluminium Planetary Carrier Shaft, 1 piece
- MR115-2RS Bearings, total 6 bearings
- Galileo 2 Extruder Screw Kit, 1 set
- MR148-2RS Bearings, 2 bearings
- 5X16mm pin shaft, 2 pieces
- M3 Tension Thumb Screw, 1 piece
- Bowden Coupler ECAS04, 1 piece
- Customised Extruder Large Gear 16mm, 1 piece
- Amazing Galileo 2 sticker
Spar Part Listing: https://store.dremc.com.au/products/ldo-galileo-2-g2e-g2z-spare-parts
Documentation:
More Info: https://github.com/JaredC01/Galileo2
Klipper Settings:
[extruder]
rotation_distance: 47.088
gear_ratio: 9:1
microsteps: 16[tmc2209 extruder]
run_current: 0.6
