Cartographer Probe v4 - CAN & USB

Cartographer3DSKU: C-PROBE-V4-ADXL-ST

Options: Standard Edition (USB)
Price:
Sale price$84.60 AUD

Shipping calculated at checkout

Visa Mastercard American Express PayPal Afterpay Zip Apple Pay Google Pay

Stock:
In stock (10 units), (Australia Stock)

Buy from the experts, who use and repairs 3D printers every day. Have a question or need compatibility check? Contact us

Do you require larger qty or commercial/education net payments or quoting? Click here for more details

Description

Introducing the Cartographer Probe v4: The Ultimate Eddy Current Displacement Sensor for 3D Printers

Note - board are pre-flashed with USB Firmware, so you may have to re-flash yourself to suit your installation if you wish to use in CAN mode, instructions on how to do this are available at cartographer3d documentation site https://docs.cartographer3d.com

What is new?

Cartographer V4 not only introduces a new All in One Design, but improved thermal and electrical reliability.

  • Faster and more powerful MCU Rated to 125oC*
  • Simple and Reliable All in One Design**
  • Increased Accuracy with refined coil routing and design
  • Updated and Improved USB Cable
  • No more bridging pads for DFU mode (we gave you holes)

* Although most components are rated up to 125C, we do not recommend going above 110C ambient temperature.

** Please note, Cartographer design is slightly different to Cartographer competitor's H variety, please check the CAD. V4 is compatible with a majority of Cartographer V3 mounts.

This latest version allows for you to switch between using either CAN or USB via Firmware, no need to re-solder anything.

Cartographer and CAN

CAN provides easy and simple wiring, no need to run multiple wires from your MCU, or use one of your limited number of USB ports, just tap into your Toolheads CAN ouput, and enjoy a seemless setup.

It is recommended to run your CAN network at a baudrate of 1,000,000.

Input Shaping (adxl345)

The probes proximity to your printers nozzle, the adxl345 provides a higher level of accuracy when running input shaper than motor mounted alternatives.

Specification:

  • MCU: stm32g431
  • Connectivity: CAN & USB via 4 pin Genuine Molex Sherlock connector.
  • Firmware Requirement: Klipper
  • Temperature Rating: It is recommended to operate Cartographer v4 in no higher than 110C, many components are rated higher than that.

The only component not rated for high temperature is the ADXL345, this was a choice to keep the price down, we have observed no issues running ADXL345 at higher temperatures, though we don't recommend relying on it for input shaping after prolonged use over 85.

What is included?

  • 1 x Cartographer Probe V4
  • 1 x 1.8m USB Cable (USB-A to Genuine Molex Sherlock)
  • 1 x 18cm CAN Cable (DuPont to Genuine Molex Sherlock)
  • 1 x Silicone Nozzle Brush
  • 1 x Cartographer V4 Fastener Pack

Which version should I buy?

  • Standard Edition - Ideal for Voron StealthBurner, Annex etc
  • Low Profile Edition - Perfect for VzBot and RatRig Printer

Currently Cartographer do not support delta printers.

Benefits:

  • Optimize Print Quality: Accurate bed leveling leads to higher quality prints—say goodbye to imperfections and defects.
  • Save Time: Faster scans and fewer print retries mean you complete your projects in record time.
  • Resource Efficiency: Accurate first-time prints mean less waste of filament and other materials.
  • Peace of Mind: Knowing your printer’s bed is perfectly leveled allows you to focus on your creative journey, not on troubleshooting.

Which version should I buy?

  • Standard Edition - Ideal for Voron StealthBurner, Annex etc
  • Low Profile Edition - Perfect for VzBot and RatRig Printers

Currently Cartographer do not support delta printers.
